Embedded Library

Getting Started With Using the Library

To use this library:

• add the desired modules (.c files) to your project with any cooresponding hal_ c files. – do not add hal_timing.c when adding timing.c (this is a single exception)
• add the \ include directory to the compilers include directories
• add the \ hal \ processor_family \ processor_number directory to the compilers include directories
• enjoy

For example to make a simple project which says "Hello World" every 10 seconds you would add the following c files to your project:

• buffer.c (used by the UART module)
• buffer_printf.c (optional - used by the UART module if you use UART_printf)
• hal_uart.c (found in the hal \ processor_family \ processor_number folder
• list.c (used by the task management module)
• task.c
• timing.c (used by the task management module)
• uart.c

Your project_settings.h may look something like the following:

#ifndef _PROJECT_SETTINGS_H_
#define _PROJECT_SETTINGS_H_

// include the library header
#include "library.h"
// let the system know which lower level modules are in use
// this way higher modules can selectively utilize their resources
#define USE_MODULE_TASK
#define USE_MODULE_TIMING
#define USE_MODULE_LIST
#define USE_MODULE_BUFFER
#define USE_MODULE_BUFFER_PRINTF
#define USE_MODULE_UART

//hint: the MSP430F5529 uses UART1 for the builtin MSP Application UART1 virtual COM port
#define USE_UART2

// hint: the default clock for the MSP430F5529 is 1048576
// the default clock for the PIC32MX is set by configuration bits
#define FCPU     8000000L
// if peripheral clock is slower than main clock change it here
#define PERIPHERAL_CLOCK FCPU

#endif // _SYSTEM_H_

The main for this project may look something like this:

#include "library.h" // for useful macros and int defs
#include "project_settings.h"
#include "timing.h"
#include "task.h"
#include "uart.h"
#include "hal_general.h" // for definition of EnableInterrupts

// define which uart channel to use
#define UART_CHANNEL 2
void hello_world(void) {
    UART_Printf(UART_CHANNEL, "Hello World\r\n");
}
int32_t main(void)
{
    // do any device specific configuration here
    // SYSTEMConfig(FCPU, SYS_CFG_ALL); // config clock for PIC32
    // WDTCTL = WDTPW | WDTHOLD;    // Stop watchdog timer for MSP430

    Timing_Init(); // initialize the timing module first
    Task_Init(); // initialize task management module next
    UART_Init(UART_CHANNEL);
    // enable interrupts after modules using interrupts have been initialized
    EnableInterrupts();
    Task_Schedule(hello_world, 0, 10000, 10000);
    while(1) SystemTick();
}
